Weight, Balance & Loading

Weight is the drone’s mass; balance is where that mass sits. Both have hard limits: weight against the 55-pound Part 107 ceiling and the manufacturer’s lower number, and balance against a CG envelope measured in inches or millimeters from a reference point. The exam’s version of this topic is arithmetic you can do on a napkin — weight times arm equals moment — and this lesson works it until it’s automatic, because on a real aircraft, an out-of-envelope CG announces itself as a drone that flies wrong.

Why Weight Matters

Every drone has a Maximum Takeoff Weight (MTOW). Under Part 107 the absolute ceiling is 55 lb (§107.3, everything on board or attached included); your aircraft’s manufacturer limit is usually lower and always controlling.

Effects of Weight on Performance

• Heavier = longer takeoff run, reduced climb, sluggish response, shorter endurance, less margin for wind
• Lighter = the opposite of every line above

The mechanism (lesson 13): more weight demands more lift, more lift demands more thrust or angle of attack, and both cost battery. Weight is endurance, spent by the pound.

The Vocabulary of Loading

• Empty weight: the aircraft as it ships — airframe, motors, integrated hardware — without battery or payload
• Useful load: MTOW − empty weight — everything you’re allowed to add: batteries, cameras, sensors, tethers, labels
• Payload: the part of the useful load that earns money
• Arm: the horizontal distance from a reference datum (an arbitrary fixed point, usually the nose or the CG station) to where a weight sits
• Moment: weight × arm — a weight’s rotational contribution about the datum
• Center of gravity: total moment ÷ total weight — the balance point, which must land inside the manufacturer’s CG envelope

The Weight-and-Balance Calculation, From Scratch

The whole system is three steps and one division:

1. Multiply each item’s weight by its arm to get its moment
2. Add all the weights, and separately all the moments
3. Divide total moment by total weight — that quotient is the CG location

Worked Problem

A quadcopter with datum at the nose. Component stations (distances measured from the nose):

Item	Weight (lb)	Arm (in)	Moment (lb-in)
Airframe + motors (empty)	2.10	5.0	10.50
Flight battery	0.60	4.5	2.70
Integrated camera	0.25	6.0	1.50
Add-on spotlight	0.30	8.5	2.55
Totals	3.25	—	17.25

CG = 17.25 ÷ 3.25 = 5.31 inches from the nose.

Now the check that matters: the manufacturer’s CG envelope for this airframe runs 4.5 to 5.5 inches. 5.31 is inside — legal and stable, though near the aft end. Had the spotlight been a heavier payload at the same station — say 0.50 lb at 8.5 in — the total becomes 3.45 lb and 17.675 lb-in, CG = 5.12 in: still inside, but note how fast a half-pound at the far arm drags the balance point.

Reading the Result

• CG too far forward (below the forward limit): nose-heavy; on a multirotor, the rear motors work harder, hover trim biases forward, and pitch authority for fast rearward motion shrinks
• CG too far aft: tail-heavy; unstable pitch behavior, oscillation, and — the classic sign — a drone that wanders or over-rotates in hover despite correct inputs
• CG out laterally (one side heavy, e.g., a single-side payload): the loaded-side motors run hotter and the aircraft rolls against trim

CG Effects: Why the Envelope Exists

The CG determines how much control authority the flight controller has to work with. A quadcopter holds hover by differential thrust — the motors on the heavy side or the CG-offset side carry more load. As the CG moves toward an envelope edge, one pair of motors approaches its thrust ceiling: the headroom for maneuvering, fighting wind, or surviving a motor degradation shrinks to zero. An out-of-envelope CG isn’t a paperwork violation on a drone — it’s an aircraft that cannot be controlled with the thrust available, which is why the check happens before the flight, on a scale and a balance point, not in the air.

Practical Weighing

For real operations, CG work is simpler than the table suggests but not skippable:

• The two-finger balance test: support the aircraft at opposite points (front/rear, then left/right) near the expected CG — it should sit level or within the manual’s tilt tolerance
• The scale check: weighed as-flown (battery in, payload on) against MTOW — the number pilots skip and regret
• After any configuration change: new camera, bigger battery, module, props — rerun both checks. The CG envelope belongs to a specific configuration.

Weight Changes During Flight

Drone batteries shed grams, not pounds — negligible. But payload release operations (dropping, spraying, casting) shift the CG and the weight mid-flight: an aircraft balanced for a full seed hopper flies differently at empty, and the useful-load math must hold at both ends of the flight, not just takeoff.

Key Facts to Walk In With

ACS references: IV.A.K1a–b

• 55 lb absolute; manufacturer MTOW controlling
• Useful load = MTOW − empty weight
• Moment = weight × arm; CG = total moment ÷ total weight
• Big arm beats big weight for moving the CG
• Forward CG = stable but heavy-handed; aft CG = unstable; both eat control authority
• Payload-release missions: weight and balance at takeoff AND at empty

Quick Check

Q: What happens to performance as weight increases? A: Every category degrades — takeoff run, climb, response, endurance, wind margin.

Q: What is center of gravity? A: Total moment divided by total weight — the balance point, which must sit inside the envelope.

Q: A 0.4-lb battery at arm 4.0 in and a 0.2-lb sensor at arm 9.0 in — which pulls the CG further aft? A: The sensor: 1.8 lb-in of moment against the battery’s 1.6 lb-in. Less weight, more leverage.

Q: Your drone carries a releasable payload. When must the CG be within limits? A: Throughout the flight — with the payload aboard and after release.

What’s Next?

Now let’s look at specific performance metrics: takeoff distance, climb rate, and endurance, plus how environmental conditions affect them.

---
