Wiring Everything Together

The Most Technical Step

This is the lesson where most builders feel some hesitation. Soldering makes people nervous, and for good reason. A bad solder joint can cause your drone to crash or even catch fire. Take your time. There is no rush.

Start by preparing your soldering iron. Clean the tip, apply fresh solder to tin it, and set temperature to around 350 degrees C. Have flux handy. It makes soldering to the PDB much easier.

Soldering ESC Power Wires to the PDB

Your PDB has clearly marked positive (+) and negative (-) pads. Solder the red ESC power wire to a positive pad and the black wire to a negative pad. Repeat for all four ESCs.

Apply iron to the pad first, then add solder. Do not heat the wire directly or you will melt the insulation. Work quickly to avoid lifting pads from the PDB.

Give each joint a gentle tug after soldering. If it comes loose, redo it. A joint that fails in flight means a motor stops spinning.

Connecting ESC Signal Wires to the Flight Controller

Each ESC has a small signal cable with three wires. Locate the signal header pins on your flight controller, typically labeled 1-4 or M1-M4.

Position each connector so the white (signal) wire sits on top. The ground wire (black) goes on bottom. Match ESC 1 to pin 1, ESC 2 to pin 2, and so on. This order must match your motor positions from the previous lesson.

Use small pieces of tape or a marker to label which ESC goes to which motor. This saves massive headaches during troubleshooting.

Connecting the Receiver

Your receiver needs at least four channels for basic flight control. Connect it to the flight controller’s receiver pins using the provided cable or jumper wires. SBUS receivers use a single signal wire. PWM receivers need individual wires for each channel.

Mounting Components

Mount your GPS module on a mast or raised position at least 5cm above the ESCs. ESCs create electrical noise that disrupts GPS signals. The higher the better.

Mount your flight controller using a vibration-dampening foam pad. Some FCs ship in a small cardboard box that works surprisingly well as a mounting plate when cut to size.

Attach battery Velcro to the bottom plate. Use industrial-strength Velcro and secure it with zip ties through the frame holes for extra holding power.

Final Wire Management

Route all wires cleanly along frame edges. Use small zip ties to bundle wires together and keep them away from spinning props. Do a visual inspection and gently tug every connection.

Never connect a battery until you have verified every connection twice. A reversed wire can destroy your flight controller instantly.

Quick Check

Q: Which wire color indicates signal on ESC signal cables? A: White is the signal wire and should be positioned on top when connecting to the flight controller.

Q: Why should the GPS be mounted away from ESCs? A: ESCs create electrical interference that can disrupt GPS signals. Mount GPS high on a mast for best results.

Q: What is a simple way to vibration-mount a flight controller? A: Use the cardboard box the FC shipped in, cut to size, with foam tape underneath. It is cheap and effective.

What’s Next?

With everything wired up, your drone is physically complete. Now we need to give it a brain by installing firmware and configuring software.

---
